146. LRU Cache

Intuition

An LRU cache is designed to store a fixed number of key-value pairs with efficient operations:

• get(key): Retrieves the value associated with the key. If the key exists, it marks it as recently used (moves to the front). If not, returns -1.
• put(key, value): Updates the value if the key exists or adds a new key-value pair. If adding a new pair exceeds the capacity, it evicts the least recently used key.

The goal is to achieve O(1) average time complexity for both get and put operations.

Approach

Data Structures:

1. Dictionary (cache): Stores key-value pairs for fast access.
2. Doubly Linked List (dll): Maintains the order of keys based on usage, where the front represents the most recently used and the back represents the least recently used. - Nodes (Node): Each node contains key, value, prev, and next pointers.

Operations:

1. Initialization (__init__): - Initializes the cache with the given capacity. - Sets up the cache dictionary and the doubly linked list (dll).
2. get(key) Operation: - If the key exists: - Retrieve the value from the cache. - Move the corresponding node to the front of the dll to mark it as recently used. - Return the value. - If the key doesn't exist, return -1.
3. put(key, value) Operation: - If the key exists: - Update the value in the cache. - Move the corresponding node to the front of the dll to mark it as recently used. - If the key doesn't exist: - Create a new node with the key-value pair. - Add it to the front of the dll and store it in the cache. - If adding exceeds the capacity, remove the least recently used node (from the back of the dll and cache).
4. Utility Methods: - _move_to_front(node): Moves a given node to the front of the dll. - _remove_node(node): Removes a node from the dll.

Complexity

Time Complexity:

Both get and put operations run in O(1) average time due to the use of hash maps (cache) for fast lookups and doubly linked lists (dll) for efficient node management.

Space Complexity:

O(capacity) for storing key-value pairs and O(capacity) for maintaining the doubly linked list structure, making it linear with respect to the cache capacity.

Code

C++

class LRUCache {
public:
    LRUCache(int capacity) : capacity(capacity) {}

    int get(int key) {
        auto it = cache.find(key);
        if (it == cache.end()) {
            return -1;
        } else {
            // Move the accessed key-value pair to the front of the list
            usage.splice(usage.begin(), usage, it->second.second);
            return it->second.first;
        }
    }
    void put(int key, int value) {
        auto it = cache.find(key);
        if (it != cache.end()) {
            // Update the value and move to the front of the list
            it->second.first = value;
            usage.splice(usage.begin(), usage, it->second.second);
        } else {
            if (cache.size() >= capacity) {
                // Remove the least recently used element
                int lruKey = usage.back();
                usage.pop_back();
                cache.erase(lruKey);
            }
            // Insert the new key-value pair
            usage.push_front(key);
            cache[key] = {value, usage.begin()};
        }
    }
private:
    int capacity;
    std::list usage; // Stores keys in order of usage
    std::unordered_map::iterator>> cache; // Stores key-value pairs and their usage list iterators
};

Python

class ListNode:
    def __init__(self, key=None, value=None):
        self.key = key
        self.value = value
        self.prev = None
        self.next = None

class LRUCache:
    def __init__(self, capacity: int):
        self.capacity = capacity
        self.cache = {}
        self.head = ListNode()
        self.tail = ListNode()
        self.head.next = self.tail
        self.tail.prev = self.head

    def get(self, key: int) -> int:
        if key not in self.cache:
            return -1

        node = self.cache[key]
        self._move_to_front(node)
        return node.value

    def put(self, key: int, value: int) -> None:
        if key in self.cache:
            node = self.cache[key]
            node.value = value
            self._move_to_front(node)
        else:
            if len(self.cache) == self.capacity:
                self._evict()

            new_node = ListNode(key, value)
            self.cache[key] = new_node
            self._add_to_front(new_node)

    def _move_to_front(self, node: ListNode) -> None:
        # Remove node from current position
        node.prev.next = node.next
        node.next.prev = node.prev
        # Add node to front
        self._add_to_front(node)

    def _add_to_front(self, node: ListNode) -> None:
        next_node = self.head.next
        self.head.next = node
        node.prev = self.head
        node.next = next_node
        next_node.prev = node

    def _evict(self) -> None:
        if len(self.cache) > 0:
            evict_node = self.tail.prev
            del self.cache[evict_node.key]
            evict_node.prev.next = self.tail
            self.tail.prev = evict_node.prev

Java

class LRUCache {
    private final int capacity;
    private final HashMap cache;
    private final LinkedHashSet usage;

    public LRUCache(int capacity) {
        this.capacity = capacity;
        this.cache = new HashMap<>();
        this.usage = new LinkedHashSet<>();
    }
    public int get(int key) {
        if (!cache.containsKey(key)) {
            return -1;
        }
        // Move the accessed key to the end to show that it was recently used
        usage.remove(key);
        usage.add(key);
        return cache.get(key);
    }
    public void put(int key, int value) {
        if (cache.containsKey(key)) {
            // Remove the old key to update its position in usage
            usage.remove(key);
        } else if (cache.size() >= capacity) {
            int lruKey = usage.iterator().next();
            usage.remove(lruKey);
            cache.remove(lruKey);
        }
        cache.put(key, value);
        usage.add(key);
    }
}

JavaScript

/**
 * @param {number} capacity
 */
var LRUCache = function(capacity) {
    this.queue = new Map();
    this.capacity = capacity;
};
/**
 * @param {number} key
 * @return {number}
 */
LRUCache.prototype.get = function(key) {
    if(this.queue.has(key)){
        const value = this.queue.get(key);
        this.queue.delete(key);
        this.queue.set(key, value);
        return value;
    }
    return -1;
};
/**
 * @param {number} key
 * @param {number} value
 * @return {void}
 */
LRUCache.prototype.put = function(key, value) {
   if(this.queue.has(key)) {
    this.queue.delete(key);
    this.queue.set(key, value);
   } else {
    if(this.queue.size >= this.capacity){
        const [firstKey] = this.queue.keys();
        this.queue.delete(firstKey);
    }
    this.queue.set(key, value)
   }
};
